200 Ton Hyd. Servo Press
|
Pressing Capacity |
200 ton |
Piston Dia
|
350 mm |
Piston Stroke |
600 mm |
Die shut height
|
500 mm |
Bolster size
|
1,000*450mm
|
하강속도 |
100 mm/s
|
가압속도 |
5mm/s |
Working Pressure |
210 bar |
|
|
| |
 |
| |
 |
400 Ton Hyd. Servo Press
|
Pressing Capacity |
400 ton |
Piston Dia
|
460 mm |
Piston Stroke |
1,000 mm |
Die shut height
|
600 mm |
Bolster size
|
2,400*1,600mm
|
하강속도 |
150 mm/s
|
가압속도 |
4mm/s |
Working Pressure |
250 bar |
|
|
| |
 |
| |
 |
600 Ton Hyd. Servo Press
|
Pressing Capacity |
600 ton |
Piston Dia
|
530 mm |
Piston Stroke |
1,000 mm |
Die shut height
|
600 mm |
Bolster size
|
2,500*1,500mm
|
하강속도 |
75 mm/s
|
가압속도 |
4mm/s |
Working Pressure |
280 bar |
|
|
| |
 |
| |
 |
2500 Ton Hyd. Servo Press
|
Pressing Capacity |
2,500 ton |
Piston Dia
|
520 mm*5ea |
Piston Stroke |
300 mm |
Max. daylight |
2,000 mm |
Min. daylight |
500 mm |
Bolster size
|
3,500*2,400 mm |
Closing speed |
400 mm/s |
Opening speed |
250 mm/s |
Working closing speed
|
1 mm/s |
Working Pressure |
250 bar |
|
|
| |
|
| |
| |
|
